ELECTRICAL, WIRE HARNESS 1
1
2
3
4
5
6
7
8
9
10
11
12
12
13
14
15
16
17
18
19
20
1
FUSE MINI BLADE 15 AMP
2410280
£11,02 Unit Price incl. VAT
2
FUSE 5 AMP
4011652
£15,55 Unit Price incl. VAT
3
RELAY SPST 12V 20A EPXY HFA
4016819
£41,89 Unit Price incl. VAT
4
FUSE-7.5 MINI BLADE (BROWN)
4011068
£15,55 Unit Price incl. VAT
5
FUSE-25A MINI BLADE
4011653
£12,40 Unit Price incl. VAT
6
FUSE IGNITION 10 AMP
2434016
£8,01 Unit Price incl. VAT
7
COVER FUSEBOX JCASE
4013565
£60,15 Unit Price incl. VAT
8
FUSE CARTRIDGE 40A
4013891
£35,90 Unit Price incl. VAT
9
FUSE CARTRIDGE 50A
4013892
£29,92 Unit Price incl. VAT
10
FUSEBOX JCASE SPEED CLIPS
4016551
£92,97 Unit Price incl. VAT
11
HARNESS-CHASSIS HWLC G1 V1 [INCL. 1-13 15 16 20]
2415258
£1 632,57 Unit Price incl. VAT
12
CLIP-CONNECTOR GREY
4018311
£4,37 Unit Price incl. VAT
13
COVER-CONNECTOR SAE
4015736
£6,41 Unit Price incl. VAT
14
SCREW
7518803
£5,46 Unit Price incl. VAT
15
COVER DIAGNOSTIC W/CLIP
4012170
£12,40 Unit Price incl. VAT
16
COVER-TYCO 4P
4018135
£8,26 Unit Price incl. VAT
17
CLAMP RUBBER COATED
7081116
£8,45 Unit Price incl. VAT
18
SCREW HXFLG
7517704
£8,45 Unit Price incl. VAT
19
CLIP-ROUTING
7081496
£5,63 Unit Price incl. VAT
20
CLIP-ROUTING [EXCLUDES CALIF. INTL.]
7082073
£28,56 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
